Model: TMA 2 (New Generation Strapping Technology)
This entry-level model offers compact design and reliable strapping for small-scale operations.
Applications:- Corrugation industry, Box packaging
- Paper industry
- Light application
- Bulk production
- Strap Width: 5–15 mm (Adjustable)
- Tension: 0–45 kg max
- Speed: 2.5 sec/strap (Adjustable)
- Power: 220V / 50Hz
- Box Size: Min-60 mm, Max-Any Size
- Top Thickness: 1 mm Thickness Steel
Model: KH 90
This advanced model is suitable for industrial use with improved speed and durability.
Applications:- Light to medium boxes
- Metal products, Wooden & Plastic crates
- Strap Width: 9,12,15 mm
- Tension: 5–50 kg (Variable)
- Speed: 2.5 sec/strap
- Power: 1 Phase, 230V AC motor
- Box Size: Min. 60 mm, Max - Any Size
- Top Thickness: 1.2 mm Stainless Steel
Model: TMA 101A (Fully Automatic Strapping Machine)
The TMA 101A is a fully automatic strapping machine designed for high-speed and consistent strapping of cartons and packages in industrial environments.
Applications:- Carton box packaging
- Logistics and dispatch centers
- Printing and paper industries
- FMCG and pharma packaging lines
- Strap Width: 9 mm, 12 mm, 15 mm (Adjustable)
- Tension Range: 10–70 kg (Adjustable)
- Strapping Speed: 2.0 seconds per cycle
- Power Supply: 220V / 50Hz / Single Phase
- Frame Size: 850 mm (W) x 600 mm (H) (customizable)
- Control: PLC-based operation with touchscreen
- Features: Auto strap feeding, loop ejector, sensor-based operation
Model: TMA 101E (Advanced Automatic Strapping System)
The TMA 101E is a high-performance automatic strapping machine designed for reliable, efficient, and consistent strapping of medium to large packages.
Applications:- Heavy-duty packaging industries
- Metal & plastic crates packaging
- Corrugated box bundling
- Textile and warehouse packaging
- Strap Width: 9 mm, 12 mm, 15 mm
- Tension Range: 5–50 kg (Variable)
- Strapping Speed: 2.5 seconds per strap
- Power: 1 Phase, 230V AC Motor
- Box Size: Min. 60 mm, Max. Any size
- Table Surface: Stainless Steel (1.2 mm thickness)
- Automation: Sensor-based auto strapping, loop ejector
Model: TMA-500HS (High-Speed Fully Automatic Strapping System)
The TMA-500HS is a high-speed, fully automatic strapping machine designed for continuous packaging lines.
Applications:- Corrugated box packaging
- Heavy-duty warehouses
- Logistics and e-commerce packaging lines
- Textile, food, and pharmaceutical industries
- Strap Width: 9 mm, 12 mm, 15 mm
- Tension Range: 5–50 kg (Adjustable)
- Strapping Speed: 2.0–2.5 sec/strap
- Power: 1 Phase, 230V AC Motor
- Box Size: Min. 60 mm, Max. Any Size
- Top Thickness: 1.2 mm Stainless Steel Table
- Features: Loop ejector, fault indicator, auto strap refeed
Model: TMA-102A (Fully Integrated Online Strapping System)
The TMA-102A is an advanced, fully automatic online strapping system designed for seamless integration with conveyorized packaging lines. It ensures high-speed, consistent, and reliable strapping for continuous operations with minimal human intervention.
Applications:- High-volume production lines
- Corrugation & carton manufacturing
- Distribution centers and logistics hubs
- FMCG and export packaging units
- Strap Width: 9 mm, 12 mm, 15 mm (PP Strap)
- Tension Range: 10–60 kg (Adjustable)
- Strapping Speed: Up to 30 cycles/minute
- Power Supply: 3 Phase, 415V / 50Hz
- Arch Size: Customizable as per line configuration
- Conveyor Integration: Compatible with roller or chain belt conveyors
- Features: Auto strap feed, jam detection, PLC controlled interface, fault alarms
Model: TMA 101A+FJID (Fully Automatic Strapping with Side Sealing)
The TMA 101A+FJID is a specialized fully automatic strapping machine with integrated side sealing mechanism. Ideal for moisture-sensitive packages and dusty environments, ensuring durable and secure strapping with minimal maintenance.
Applications:- Heavy-duty packaging lines
- Carton and corrugated box strapping
- Food, pharmaceutical, and chemical industries
- Export and warehousing operations
- Strap Width: 9 mm, 12 mm, 15 mm (PP Strap)
- Tension Range: 10–80 kg (Adjustable)
- Strapping Speed: Up to 25 cycles/minute
- Power Supply: 3 Phase, 415V / 50Hz
- Sealing Type: Side Sealing (Dust & Moisture Protection)
- Arch Size: Customizable as per package size
- Features: Auto strap feed, jam detection, PLC controlled system, easy maintenance design
Model: TMA FJ-1D (Side Sealing Strapping System)
The TMA FJ-1D is designed for secure side sealing strapping, ideal for dusty, wet, or harsh environments. With its advanced sealing technology, it ensures strong and durable strapping for a variety of industrial packaging needs.
Applications:- Heavy industries & warehouses
- Food, chemical & pharmaceutical packaging
- Moisture-sensitive products
- Corrugated and wooden boxes
- Strap Width: 9 mm, 12 mm, 15 mm (PP Strap)
- Tension Range: 10–80 kg (Adjustable)
- Strapping Speed: Up to 20 cycles/minute
- Power Supply: 3 Phase, 415V / 50Hz
- Sealing Type: Side Seal (Dust & Water Protection)
- Arch Size: Customizable
- Features: PLC Control, Jam Detection, Auto Strap Feed, Low Maintenance
Model: TMA SQ450 + TMA 305RP (Fully Integrated Online Strapping System)
The TMA SQ450 + TMA 305RP is a fully integrated packaging and strapping solution combining carton sealing, squaring, and automatic strapping in a seamless conveyor line. Ideal for high-speed automated production facilities.
Applications:- Export packing units
- High-speed distribution centers
- FMCG and e-commerce packaging
- Warehouse & logistics hubs
- Strap Width: 9 mm, 12 mm, 15 mm (PP Strap)
- Tension Range: 10–70 kg (Adjustable)
- Strapping Speed: Up to 30 cycles/minute
- Power Supply: 3 Phase, 415V / 50Hz
- Functions: Auto Carton Squaring, Sealing, and Strapping
- Integration: Complete Conveyor Line Integration
- Features: PLC Control, Jam Detection, Auto Strap Feed, Low Downtime
